Angled Banner Print File SOP
To show how to create print files for angled banners
To show how to create print files for angled banners
1
Step 1 of 9

Open up the working file for the angled banner

2
Step 2 of 9

Create a new artboard at any size.

3
Step 3 of 9

Copy the banner artwork to the new blank artboard, centre and fit the artboard to the artwork

4
Step 4 of 9

PERFORM ANY BANNER FINISH-SPECIFIC ADJUSTMENTS

5
Step 5 of 9

Rotate the banner to be flat.

The number of degrees that the banner needs to be rotated to be flat can be found in either

  • The "Rotate" field in Illustrator
  • The original measure-up document
  • Excel Document created for Keda Edged banners
6
Step 6 of 9

Fit the artboard to the selected artwork

7
Step 7 of 9

Add a pink banner ends on both ends of the artwork

8
Step 8 of 9

Select All and fit Artboard to Selected art

9
Step 9 of 9

Save the print file in the correct production folder using the standard file naming convention
