Installation of R and R windshield washer

This is how to install your new windshield washer

Step 1 of 67

Alright, going forward with the installation, we're going to start with our driver's side washer jet, the one right at the end of the hose here.

Step 2 of 67

As you look at your bonnet, you've got to get tucked right under here to find that first washer jet square.

Step 3 of 67

See that's it right there in the centre, and just over to the right of it is the mount clip.

Step 4 of 67

So we're just going to pop that end jet right in that square hole. So as we pop the jet in, you'll see that's the reason why it's a square hole.

Step 5 of 67

It's got two spring clips, you're literally pushing it in and both those clips will lock into place and it's going to point towards your windscreen.

Step 6 of 67

It's on a universal joint here too, so you can aim this exactly where you want it on the windshield.

Step 7 of 67

So if it's spraying somewhere that it shouldn't be, you can just aim that quite simply.

Step 8 of 67

The way to aim it is a small flat blade screwdriver. A little precision one or something like this is perfect.

Step 9 of 67

You can go straight into that there by just popping the flat blade into that universal and you can move it up and down, up and down.

Step 10 of 67

You can actually twist it this way. You can move it all over the shop. So if it's not spraying in exactly where you need it when it arrives, you just aim it with this jet.

Step 11 of 67

So generally start with it in the middle and then if you need to move it up or down, once it's on the vehicle it's not too hard.

Step 12 of 67

If you just put your flat blade in then you can move it up or down or twist it to get it exactly where you need it.

Step 13 of 67

So what you want to do is start with the washer jet right at the end of the hose. Just lay it out on the driver's side and run the rest of the hose just on top of the old system right across to the other side there on the passenger side.

Step 14 of 67

Once you've done that you want to locate the square hole. So if you haven't already, make sure you familiarise yourself with where that square hole is.

Step 15 of 67

Don't try and shove it in this one. Don't try and shove it in this one. It's not going to go. It's going to go in under here.

Step 16 of 67

Tucked away right at the front here. You get your washer jet.

Step 17 of 67

You point it towards the windscreen. That's where you want it to spray. So once the bonnet's down it's going to be just poking its head out there playing a game of peek-a-boo and just squirting it out the windscreen.

Step 18 of 67

So what you do is just line your square up and push it in. Make sure it doesn't fall out.

Step 19 of 67

Give it a little wiggle. Give it a little movement there just to make sure it's locked in fully.

Step 20 of 67

You might have to just push it up. But just be careful you don't break any of this. It's only plastic okay guys.

Step 21 of 67

So just be careful. Give it a little wiggle. Make sure it's locked in. That's definitely locked in there.

Step 22 of 67

Then after you've got that first jet in it's literally just a matter of following these clips along.

Step 23 of 67

They're all spaced out in exactly the right locations. You've got an oval clip there. Line that up and push it in.

Step 24 of 67

You'll hear it click in. That's that one done. It's locked in. First clip done.

Step 25 of 67

So once your first clip's done just move along to your second clip here. Get another little oval clip.

Step 26 of 67

Push him in. Locked in. Give him a little wiggle there.

Step 27 of 67

It's all fine. The next clip is the square one with the Y piece for the other jet.

Step 28 of 67

That's the square piece that I was talking about there for the square hole. Got the Y piece and you just put it in this way.

Step 29 of 67

So the Y, the bottom part of the Y goes off to the jet. Top part's in the system.

Step 30 of 67

You can't mess this up guys. It's that easy. Push in. Nice and simple.

Step 31 of 67

Alright after you've got the square one in locate the other hole down here. Your square hole.

Step 32 of 67

Make sure you know where it is. Again don't go popping it in these oval ones up the top here. Down the bottom it's the square one.

Step 33 of 67

And it's exactly the same as before. Face the washer jet towards the front.

Step 34 of 67

Find your hole and push it in. That's it. Just get it to clip in. Nice and simple.

Step 35 of 67

Just like that. Don't forget to give it a little wiggle. Make sure it's not sitting down because if it's sitting down it's not going to be spraying in the right spot.

Step 36 of 67

If it's clipped in there it can't go anywhere. It's aiming in exactly the right location.

Step 37 of 67

Once we've done that we move along this one more mount hole here. So we get the clip.

Step 38 of 67

Same thing. Push it in. You'll notice they're all in the right locations. So there's no drama with where they go.

Step 39 of 67

That's how simple it is. Here's your little reference mark here.

Step 40 of 67

This is the main part about the install here. How are you going to run it? You could run it straight down here and you could take that T fitting out and you could run straight onto that straight through plastic connection here on the barb.

Step 41 of 67

And you could just run the bonnet mount system. Or if you do want to run both we've already got the T in place.

Step 42 of 67

And what you can do here is you could zip tie this up to your bonnet.

Step 43 of 67

There's a big square hole there. You could zip tie it up to keep it nice and secure out of the way.

Step 44 of 67

Tuck the excess in beside the hinge there and just run your original hose that goes to your washer jet.

Step 45 of 67

Just cut it. Cut it with some scissors. That's exactly what we did. And line it up with the T fitting.

Step 46 of 67

And you can take this extra bit of the hose and this extra bit of the clip off here.

Step 47 of 67

You don't need it. So you could just run straight through off your original system. Or you can choose to cut this hose and line it in this way.

Step 48 of 67

So I'll just go through that now. That's coming down from the bonnet mount jet past the hole up there where you're going to zip tie if you want to do it that way.

Step 49 of 67

And into your original system, plug your T in. We've got the hose that's supplied here.

Step 50 of 67

And as you'll see, it's the same fitting that's on here. So what we're going to do is because we cut this hose, we're just going to use that hose.

Step 51 of 67

We're going to pop this hose off and just put that aside.

Step 52 of 67

So the reason we pop that off is it's just easier to work with the hose that we've already got. And we can push it into this existing hose that we've just trimmed it right in the middle.

Step 53 of 67

And it just tucks in nice and neat underneath that clip just there. It's all tucked away nice and neat.

Step 54 of 67

The only thing to consider is if you have a bonnet mounted UHF aerial that goes on here.

Step 55 of 67

Because it comes down that little bit extra, you may squash this hose. So if that's the case and you've got a bonnet mounted UHF aerial, what you might want to do is just redirect this hose here so it actually comes up with the other one.

Step 56 of 67

So you might want to just move it back here, your T fitting just off the side, and then run both hoses up together here.

Step 57 of 67

So it's way away from the UHF. So that's the only other thing to consider here. But that's pretty much it there.

Step 58 of 67

So there's the T in place. I didn't push it right in that last section. So yeah, you put your T in place and you tuck it in underneath this little clip that's here.
