Verify Process Line UP conditions before Start up
Verify process lineup condition before startup.
Verify process lineup condition before startup.
1
Step 1 of 23Verify process lineup condition before startup.
2
Step 2 of 23Process safety fundamentals are a set of operational rules relevant to process safety, the purpose of which is to prevent releases from equipment.
3
Step 3 of 23Scope and risks
4
Step 4 of 23This process safety fundamental applies for startup after a shutdown, isolation or modification of a line or equipment, after maintenance works or use of temporary piping.
5
Step 5 of 23The risk is related to uncontrolled pressure increases, unintentional mixing or other process anomalies.
6
Step 6 of 23These events can be caused by incorrect alignment of valves, lines or tanks or by open ends.
7
Step 7 of 23Operating instructions
8
Step 8 of 23During a maintenance turnaround, modifications and replacements can be made.
9
Step 9 of 23Before startup, physically walk along the lines, checking that the alignment and positions of valves are in the correct position.
10
Step 10 of 23The positions of valves reflect what is specified on the P&IDs.
11
Step 11 of 23In case of inconsistencies, agree the operations to be carried out with the control room and if required apply for a work permit.
12
Step 12 of 23During the walk-on field, verify that the alignment is correct, the valves, where required, are locked and the blind flanges have been removed.
13
Step 13 of 23Also check that all drains and vents are closed and fitted with plugs.
14
Step 14 of 23The required instrumentation is available and there are no leaks due to incorrect assembly of flanges or seals.
15
Step 15 of 23Check that all pipe open ends are properly closed.
16
Step 16 of 23Update the P&ID and highlight any deviations.
17
Step 17 of 23Tag the valves and the alignment conditions of the equipment on field to support subsequent identification and control.
18
Step 18 of 23Always keep in mind that possible challenges on field can be due to pipes or valves that are not easily visible.
19
Step 19 of 23Checking on the field may not be easy for the location of the element to be inspected.
20
Step 20 of 23It's limited accessibility, poor visibility at night or in bad weather conditions.
21
Step 21 of 23Reminder This video illustrates basic rules to be observed during daily activities.
22
Step 22 of 23Company procedures, operating instructions and work permits govern the execution of each intervention.
23
Step 23 of 23Not complying with them could cause damage to people, the environment, assets and have a possible impact on the company's image and reputation.
