CANOPY, SIDE LATCH ASSEMBLY

Knowby

CANOPY, SIDE LATCH ASSEMBLY

1

Step 1 of 9

2

Step 2 of 9

Fit the Deutsch pins to the end of the wires ensure green and black are joined together.

3

Step 3 of 9

Fit the M5x30 bolt to the bottom of the latch fit with M5 Nyloc.

4

Step 4 of 9

Fit wire through the hole in the bottom.

5

Step 5 of 9

Fit the latch into the latch mount.

6

Step 6 of 9

Fit 2x M6x12 bolts into the spots shown.

7

Step 7 of 9

Tighten using impact drill.

8

Step 8 of 9

Tighten the M5 Bolt

9

Step 9 of 9
