Wentex Pipe and Drape (Disassembly)
How to lower, disassemble and pack up the Wentex pipe and drape system
How to lower, disassemble and pack up the Wentex pipe and drape system
1
Step 1 of 10

Setup



Requirements

  • Two People



Equipment

  • Wentex Pipe & Drape Trolley

  • Hex Key Wrench



PPE

  • Steel Cap Boots

  • Hi-Vis Vest

2
Step 2 of 10

Lower Uprights

With one person on either side, in unison:

  • Loosen screw on upright

  • Lower poles

  • Tighten screw on upright

3
Step 3 of 10

Remove Drape

Move along the entire drape detaching it from the support beam

4
Step 4 of 10

Remove Support Beam

With one person on either side, in unison:

  • Press in silver button to release lock

  • Lift out support beam

5
Step 5 of 10

Shorten Support Beam

  • Loosen the support beam screw

  • Slide the beam pieces together

  • Tighten the support beam screw

6
Step 6 of 10

Store Uprights

  • Loosen the bottom screw

  • Lift the pole up and out of the base

  • Tighten the bottom screw

  • Place upright in trolley with screws side at the top

7
Step 7 of 10

Disassemble Base Plate

  • Flip over the base plate

  • Use the hex key to unscrew the bolt

  • Screw the bolt back into the pin

8
Step 8 of 10

Store Base Plate and Pin

Note: Store the pin with the bolt facing up

9
Step 9 of 10

Fold Drape

With two people, keep folding the drape in half until it is small enough to fit in the orange bag.

10
Step 10 of 10

Put Drape in Bag

Please reach out if you have a better way of doing this 😅
