Press the start button to get the machine ready.

Once the machine is ready, press the foot pedal to execute the first bend, creating a 90-degree angle on a 30-millimeter long flange.

Use a protractor to check the angle of the bend.

The measuring tool indicates that the angle is slightly open, measuring precisely at 91.6 degrees.

To correct the angle, touch the correction page icon on the main page.

Enter the measured angle on the correction page.

Values for axes Y1 and Y2 are automatically corrected based on the entered angle.

Check the length of the flange, which was intended to be 13 millimeters but measures 29.6 millimeters.

On the correction page, correct the x-axis value to achieve the desired dimension.

The first bend is now perfect.

Return to the main page and proceed with any other corrections needed in a similar manner.

A quick tip: Back gauge corrections can be directly applied from the main page by touching specific areas.
