Archer Barrier (Placement)
A Brief overview on how to safely pack down, relocate & re instate a Meridian Archer Barrier
A Brief overview on how to safely pack down, relocate & re instate a Meridian Archer Barrier
1
Step 1 of 7

Remove Arm Bar

Remove the locking pin from the metal arm bar in the barrier hauler.

2
Step 2 of 7

Insert Arm Bar

Slide the metal arm bar into the Archer Barrier and insert the locking pin to secure

3
Step 3 of 7

Lower Wheels

  • Remove locking pin

  • Lower wheel

  • Replace locking pin

  • Repeat

Note: You may need to hold the wheel slightly to align the holes for the locking pin to be removed and inserted

4
Step 4 of 7

Lift and Move

Line up the locking pin of the hauler with the hole in the arm bar.

Place foot on base of hauler and lean back until the front of the Archer Barrier is off the ground.

Wheel the barrier to the desired location.

5
Step 5 of 7

Lower in Place

Once in the desired location, lower the handle on the hauler back towards the Archer Barrier until the front of the barrier is back on the ground.

6
Step 6 of 7

Raise Wheels

  • Remove pin

  • Raise wheel

  • Replace pin

  • Repeat

Note: You may need to hold the wheel slightly to align the holes for the locking pin to be removed and inserted.

7
Step 7 of 7

Store Arm Bar

Remove the pin securing the arm bar to the Archer Barrier and store the arm bar and locking pin on the hauler.
