BOIX Machine 4
MTE041
MTE041
1
Step 1 of 6

Ensure adjustment handle is in place: The machine will not run if the handle isn't in its correct position.

2
Step 2 of 6

Switch on Hotmelt: Ensure green 'Ready' light is illuminated on the hotmelt glue unit.

3
Step 3 of 6

To Start Machine:

  1. Turn knob clockwise to release E-Stop
  2. Press green 'Reset' button
  3. Press white 'Start' button
  4. Turn black switch clockwise to switch on vacuum
4
Step 4 of 6

Load Blanks into Feeder: Take blank sheets from pallet and load into feeder cassette.

Note: Overfilling the cassette will cause the feeder to fail.

5
Step 5 of 6

Clearing Jam Ups: The guard can be opened to clear any jam ups in the machine. Opening the guard will stop the machine.

6
Step 6 of 6

To fill the glue pot, pour glue pellets into the hopper as shown

Caution: Glue reservoir will be hot
