Creating a part in Numerical Mode
Numercial Programming on CybTouch
Numercial Programming on CybTouch
1
Step 1 of 10

Create a new program by touching the program number in the top left corner.

2
Step 2 of 10

Select tools by touching the tool icon. Browse the tool library and choose the desired tool.

3
Step 3 of 10

Click on the materials name on the screen. Go to the "More" page. Select the pre-programmed material. Modify thickness and sigma values if needed.

4
Step 4 of 10

Explore the "Bending Length" page for sequence parameters. Locate and configure the bending length.

5
Step 5 of 10

Return to the main page. Program the first bend: Ensure the default angle is correct (90 degrees). Input the flange length (35 millimeters). Execute the bend by touching the corresponding arrow.

6
Step 6 of 10

Repeat the process for the remaining bends.

7
Step 7 of 10

Return to the first step and press the Start button.

8
Step 8 of 10

Wait for the machine to be ready (OK button).

9
Step 9 of 10

Execute the bend using the foot pedal.

10
Step 10 of 10

Save the program under a chosen number, if you plan to use this program later in the future.
