Begin by removing the front passengers inner wheel guard

Remove the bolt that mounts the window washer fluid filler to the engine bay and feed the loom behind it.

Feed the cab entry portion of the loom down into the access point at the front passengers side of the engine bay.

Unbolt the negative terminal from the side of the engine bay and attach the negative terminal from the loom and reinstall.

Fasten the looms negative terminal to the engine bay.

Feed the fuse holders and positive terminal in behind the window washer fluid filler too.

Fasten the washer fluid filler back to the engine bay.

Remove the fuse cover

Feed the rest of the loom down into the engine bay.

Continue feeding the loom down into the engine bay.

Remove the positive terminal cover and unscrew the positive terminal.

Attach the positive terminal from the loom with the fuse holders on it to the vehicle positive terminal.

Reinstall the cover

Pull the cab entry loom from the access point down into the passengers inner wheel guard.

Remove the shown fuse and install into the fuse holder supplied with the vehicle loom and plug back in.

Reinstall the fuse cover.

Remove the passengers door trim and the trim in the footwell.

Unbolt the plastic bracket from the passengers footwell.

Remove the shown rubber bung as this will give you access to the passengers foot well.

Feed the cab entry loom along the inside of the passengers wheel guard and through the shown access point.

Place the rubber grommet into where you removed the bung to seal it.

Continue feeding it through into the passengers footwell.

Reinstall the plastic mount that had removed to gain access.

Reinstall the inner guard.

Feed the beacon/buzzer harness in between the center console in the footwell.

(NOTE)

Buzzer is not installed/connected for Hardlid installations

Pull the carpet back and sit the loom in behind it.

Plug it into the plug that you have just installed through the access point.

Cable tie to the factory loom.

Reinstall the passengers side trims and rubber seal.

Remove the trim from the drivers side like you have done the passengers.

Remove the little storage compartment and plug the buzzer patch into the loom.

Plug the buzzer into the patch and stick the buzzer inside, next to the fuse box.

Reinstall the storage compartment.

Unplug the factory vehicle harness and plug one end of the central locking patch in.

Plug the other end of the central locking patch in to the factory vehicle harness.

Fasten the plugs back into place and reinstall the trim.

With the remainder of the loom, cable tie along the chassis towards the rear of the vehicle.

Reinstall the native terminal.
