Remove battery earth clamp.

Tape battery end of M2 harness to a piece of small plastic tube or wire to help feed harness up the side of vehicle chassis rail. Route harness along brake lines and up into engine bay away from any heat or pinch points.

Remove plastic tube and tape. Remove fuse from M2 harness. Route earth behind A.B.S module to line up with body earth.

Disconnect large electrical plug for access to body earth. Connect positive and earth. Reinstall large plug

Cut plug off vehicle fuel flap harness. Connect grey/brown wires to blue and purple/green wires to green. With solder splice. Heat shrink over join.

Secure harness to brake lines every 300mm with cable ties. Ensure harness is away from any heat or pinch points.

Place canopy interconnect plug beside the fuel filler, ready for canopy install.

Install fuse in central locking harness and reconnect battery earth.

After installing canopy, connect vehicle harness to canopy harness. Check lock and unlock is operating correctly and canopy lights are functioning. Tuck excess harness out of site and away from wheels etc secure with cable ties.
