Place the front of the box dog into the wellside

Place the body of the dog box in behind the front like so

Fasten the front of the dog box and divider together using M6x16 stainless steel button heads and antiseize

Bolt the top of the dog box to the front using M6x16 stainless steel button heads with antiseize

Secure the center divider using 4 x M6x16 with anti-seize.

Tighten the adjustable mounting brackets to the center and rear dividers

Ensure the brackets are level with the floor when tightened

Secure mounting clamps in place try to have clamps in each corner to ensure a good clamping surface.

Drill through the wellside using the 2x M8 holes in the center divider

Drill holes through the wellside using the M8 holes in the rear doors/divider.

Clean out wellside

Insert rubber mats

Clean out again once complete
