CCL Z2 Self-Checkout Kiosk Deployment
This guide outlines the standard sequence for setting up a card-only, freestanding CCL Z2 Self-Checkout Kiosk equipped with an Intel Core i3 processor running Windows 10 IoT.
This guide outlines the standard sequence for setting up a card-only, freestanding CCL Z2 Self-Checkout Kiosk equipped with an Intel Core i3 processor running Windows 10 IoT.
1
Step 1 of 19

Recommended Tools:

1x Phillips Head Screwdriver

1x 5mm Hex Key

1x Battery Drill with Phillips Head Bit

2
Step 2 of 19

Install the tabletop fixing bracket

Use M6×14 hexagon socket head cap screws

3
Step 3 of 19

Install the tabletop fixing bracket

Use PWM3×8 round head screws with pads to secure

4
Step 4 of 19

Install the table

Use M6×14 hexagon socket head cap screws

5
Step 5 of 19

Remove the front and rear bezels of the bracket

Used to route the power supply and network cable

6
Step 6 of 19

Install the scale power cord, scale data cable, network cable, and power cord

7
Step 7 of 19

Feed the other end of the scale power cord and scale data cable through the hole

8
Step 8 of 19

Install the electronic scale

9
Step 9 of 19

Install the acrylic fence

Use PWM4×8 round head screws with pad screws

10
Step 10 of 19

Install the tabletop fixing bracket

Use M6×14 hexagon socket head cap screws

11
Step 11 of 19

Install the warning light

Remove the screws, then install the light

12
Step 12 of 19

Install the mainframe

Fit M6×14 hex socket screws on the left and right of the bracket

13
Step 13 of 19

Pass the wire through the hole, hang the mainframe on the installed screws, then fix and tighten the screws

14
Step 14 of 19

Install the antenna

15
Step 15 of 19

Install the holder for the hand scanner

Use PWM3×8 round head screws with pads to secure

16
Step 16 of 19

Lock the back cover of the bracket

17
Step 17 of 19

Install the scale power cord, scale data cable, network cable, and power cord

18
Step 18 of 19

Data cable display

19
Step 19 of 19

Installation complete
