Micromine Momentum 2024 Beyond Product Showcase

Step 1 of 80

Hi, I'm Jeremy Hanrahan, the Product Strategy Manager for Micromine Beyond, SPRY and Elastri mine planning solutions.

Step 2 of 80

You now have next generation technology that is tailored to meet your specific needs during each planning horizon and primary mining method.

Step 3 of 80

Micromine Beyond offers robust strategic planning for open pit or underground assets, Elastri is advanced mine planning for the open pit hard rock mines, finally SPRY offers comprehensive open pit coal and soft rock mine planning.

Step 4 of 80

It's an incredibly exciting time for Micromine since the addition of Elastri and SPRY to our business.

Step 5 of 80

These industry leading tools are grounded in the philosophy of delivering precise, tailored solutions for your planning needs.

Step 6 of 80

The best practice with an Elastri and SPRY, combined with the extensive use of input, underpins the core of Micromine's mining solutions, driving enhancements and additions across the portfolio.

Step 7 of 80

Today, I'm pleased to be sharing the latest developments in Micromine Beyond that will boost your confidence and certainty when developing a life of mine plans.

Step 8 of 80

Beyond is adopted to deliver robust strategic mine plans that maximize profitability while considering the real world constraints for surface and underground mines.

Step 9 of 80

Strategic mine planners can gain an edge with access to powerful optimizers that save time and improve returns over the mining value chain.

Step 10 of 80

Beyond integrates 3D solutions without additional investment and your choice of integrated approaches when assessing the viability of mining projects.

Step 11 of 80

Beyond is chosen by strategic mine planning teams because it's built for handling large data sets, the platform efficiently handles all the information required to provide you accurate representations of your project.

Step 12 of 80

Beyond has enhanced software capability. It offers seamless integration with various software solutions, supporting all the file formats you need.

Step 13 of 80

It has streamlined strategic planning. The platform simplifies the transition from resource assessment to reserve designation.

Step 14 of 80

Purpose-built STOPE and PIT optimizers facilitate this process efficiently.

Step 15 of 80

Beyond builds effective stakeholder engagement. Impress project stakeholders by easily communicating your project with a flexible environment that enhances collaboration.

Step 16 of 80

Finally, Beyond has a robust 3D graphics engine. The software boasts a powerful 3D graphics engine called VizX, which enables detailed design of surfaces, pits, ramps, declines, shafts, drives and more.

Step 17 of 80

The journey for Beyond is one of renewed focus and continuous improvement.

Step 18 of 80

As you may be aware, Micromine has enhanced its scheduling capabilities by acquiring Elastri and Spry, both industry-leading mine scheduling tools.

Step 19 of 80

You're beginning to see the benefits of this now flowing through to Beyond. Best practice from these tools is being implemented into Beyond, and we're working to provide smooth integration between each product.

Step 20 of 80

A good example of this is related to end-of-period surfaces and how these can shape your mid-term mine schedules.

Step 21 of 80

Beyond provides a wealth of data that can be used to drastically shape mine production and help planners make informed decisions about future mining activities.

Step 22 of 80

We can now export end-of-period surfaces from your strategic schedule and use them in Elastri's Tactical Scheduler to adjust and compare scheduling options on the fly.

Step 23 of 80

Micromine is continually investing to improve Beyond, and the 2024 release is no different.

Step 24 of 80

We have introduced new features that are designed to give you certainty and confidence when assessing project feasibility for Open Pit Metals assets.

Step 25 of 80

These include improvements to strategic scheduling, which provide a holistic approach to pit optimisation and materials management.

Step 26 of 80

We have also turned our focus towards a range of blast design improvements, which bring more capability into Beyond and reduce the need for multiple tool sets.

Step 27 of 80

Designing an optimal pit is critical when determining the viability of future mining projects.

Step 28 of 80

While it's important to factor in the geotechnical constraints of the resource, the physical constraints of production must also be considered to ensure the resource can be mined economically.

Step 29 of 80

In this release, we have improved Beyond to include minimum mining width into the Beyond pit optimisation capabilities.

Step 30 of 80

This means the resulting pit shapes are consistent with real-world mining methods and equipment constraints.

Step 31 of 80

By ensuring more of the critical considerations are factored into your optimal pit, you can be more confident in your NPV from day dot.

Step 32 of 80

Strategic mine plans heavily rely on algorithms to determine an optimal open pit for a given asset.

Step 33 of 80

They systematically factor in variables to determine maximum NPV over the mine's lifespan, considering factors like mine shape and operational duration.

Step 34 of 80

However, the constraints of real production are a major factor that is difficult to account for within the conventional processes.

Step 35 of 80

Although the optimal pit accounts for the geotechnical characteristics of the resource, it's only realisable if it can be mined.

Step 36 of 80

We have addressed this problem by providing you a wider set of inputs within Beyond's pit optimisation capabilities.

Step 37 of 80

The new bench solids generator processes the nested pits from the pit optimiser bench by bench and combines them to produce solids that satisfy a minimum mining width.

Step 38 of 80

To do this, the block model is coded with a series of nested pits from the pit optimiser.

Step 39 of 80

Then, the minimum mining width is specified, depending on your mining method and your equipment.

Step 40 of 80

You will then receive output solids or you can store the extraction numbers for the combined pits within the block model.

Step 41 of 80

All of these outputs are consistent with your minimum mining width.

Step 42 of 80

By including a robust methodology for calculating minimum mining width and apply it to your pit, you can take much of the guesswork out of the process.

Step 43 of 80

There is less need for additional tools and manual calculations, saving time and the chance of errors in the process.

Step 44 of 80

Ultimately, you will now have more confidence in your NPV calculations, knowing your endgame from day dot.

Step 45 of 80

Beyond's latest release includes an improved methodology to model the flow of material within your strategic schedules, giving you more confidence and certainty when assessing the economic viability of your asset.

Step 46 of 80

The new functionality allows you to consolidate the number of tools required for your strategic planning needs and ensures a streamlined workflow during the process.

Step 47 of 80

Your planning teams will save time, reduce the risk of errors and give you the confidence to go beyond when proposing your optimal strategic schedule.

Step 48 of 80

Historically, Beyond's strategic planning tools operated within predetermined material flow assumptions that were static in nature.

Step 49 of 80

These have now been improved to include many real-world dynamics that will take your strategic planning to a new level.

Step 50 of 80

You now have the capability to apply specific constraints to different parts of the processing network.

Step 51 of 80

For instance, constraints can now be set for multiple pits, processing plant capacities, input grade requirements for each plant and much more.

Step 52 of 80

This advancement enables the optimisation process to become more dynamic, adaptable and reliable.

Step 53 of 80

An example that demonstrates this would be a mine that plans to introduce a second primary crusher to the processing plant 10 years after commencing production.

Step 54 of 80

This change will impact critical operational parameters, such as the volume of material required from the pit, all reserves needed in the stockpiles and the increased production capacity from the upgraded processing plant.

Step 55 of 80

When determining your NPV in this instance, you need to account for these changes and have the flexibility to assess many scenarios that inform your strategic plan.

Step 56 of 80

Beyond now allows for these considerations over set time horizons, which leads to much greater confidence in your calculated NPV.

Step 57 of 80

In this release, you have the power to account for and optimise material flow within your strategic schedules.

Step 58 of 80

This important feature allows you to save time and reduce errors with a seamless and streamlined workflow.

Step 59 of 80

When coupled with our new pit optimisation capabilities, you can be assured your strategic plans from beyond are robust and accurate.

Step 60 of 80

The 2024 release includes a range of blast design enhancements that integrate with the up and downstream workflows.

Step 61 of 80

Create blast designs in one place without the need for external inputs, or integrate and edit pre-existing designs without the need for intermediaries.

Step 62 of 80

The dynamic blast design feature set prioritises flexibility, allowing users to adapt the tool to their specific scheduling needs.

Step 63 of 80

You can expect a richer experience from Beyond's blast design function with the introduction of these new features.

Step 64 of 80

Here's what some of this looks like in practice. You can now import blast masters into your blast design.

Step 65 of 80

It's easy to merge blocks into and interact with your project.

Step 66 of 80

All of your CAD tools are now embedded into the blast design.

Step 67 of 80

Digitise data on the go. There is also no need for a string file of a blast block.

Step 68 of 80

The blast design is now more interactive. Quickly edit blast blocks, copy shapes, add nodes or mimic shapes.

Step 69 of 80

The 2024 release of Beyond introduces several new features aimed at enhancing your strategic planning.

Step 70 of 80

These features include improvements in strategic scheduling for pit optimisation and materials management.

Step 71 of 80

The software now offers a minimum mining width consideration for your pit designs, aligning the pit shape with practical mining methods and equipment.

Step 72 of 80

This ensures a more accurate assessment of project viability and NPV.

Step 73 of 80

Beyond now incorporates material flow considerations, streamlining the strategic planning process and reducing the need for multiple tools.

Step 74 of 80

This enhancement is expected to save time, minimise errors and boost confidence in creating optimal strategic schedules.

Step 75 of 80

Furthermore, the 2024 release also introduces enhancements for blast design.

Step 76 of 80

Users can now design pit and blast plans in a unified environment, eliminating the need for external inputs and intermediaries.

Step 77 of 80

The dynamic blast design features prioritise flexibility and adaptability, enabling users to tailor the tool to their specific scheduling requirements.

Step 78 of 80

Thank you for your time today. It has been a pleasure to introduce the new features of Beyond that give you more confidence and certainty for your strategic plans.

Step 79 of 80

For further information about our exciting Micromine releases, please keep an eye out for more information from us shortly.

Step 80 of 80

Thank you for your time.
